Airo5 LSA US

by Airo Aviation
4.3
3
Airo5 LSA US - Photo #1

Airo 5 is a single engine, all-fibreglass aircraft with two side-by-side seats. The aircraft is equipped with fixed tricycle landing gear with a steer able nose wheel. The fuselage is a fibreglass shell with fibreglass seats integrated. Safety belts are attached to the seats and to a shelf intended for putting off lightweight objects (headphones, maps, etc.).

The wing is a monospar construction with a sandwich skin composed of two layers of fibreglass and special foam. Control surfaces and Empennage is of the same construction.

Specifications

Empty weight:
645 lbs (293 kg)
MTOW:
1323 lbs (600 kg)
Stall speed:
35 kts (40 mph) (65 kph)
Cruise speed:
117 kts (135 mph) (217 kph)
VNE:
146 kts (168 mph) (270 kph)
Take-off distance:
1608 ft (490 m)
Landing distance:
1608 ft (490 m)
Engine:
100 hp Rotax 912/s engine
Fuel consumption:
4 GPH (15.1 LPH)
